Darin® Fish Feed Machine, a flagship solution for commercial aquaculture feed production. Engineered with European-standard twin-screw technology, it ensures stable, high-yield output, precise nutritional integrity, and supports the production of floating, sinking, and slow-sinking pellets.
■ All machinery is certified with European CE Approval & ISO 9001 Certification.
■ Run in 90+ countries including USA, Germany, Japan, Italy, UAE, Australia etc.
■ Machinery Supplier of General Mills, Kelloggs, Melinda, Bill Gates foundation & Wanpi.
Darin® Fish Feed Machine is an advanced, fully automatic extrusion system engineered for the production of floating, sinking, and slow-sinking aquatic feed for species such as fish, shrimp, and crab. Leveraging twin-screw extrusion technology, it delivers superior feed stability, uniform shape, and optimal nutrient preservation.
Contact us today for specifications, customization options, and expert support to optimize your pet food production line!
When purchasing the Fish Feed Machine, you might be interested in the following Technical Parameters.
| Model | Capacity | Power | Dimension |
|---|---|---|---|
| DR-65 | 120-150kg/h | 80kw | 18*5*3m |
| DR-70 | 200-300kg/h | 90kw | 20*5*3m |
| DR-85 | 500-600kg/h | 150kw | 30*5*4m |
| DR-90 | 800-1000kg/h | 200kw | 35*5*5m |
| DR-95 | 2000kg/h | 250kw | 40*10*16m |
| DR-120 | 3000kg/h | 350kw | 50*10*20m |
| DR-135 | 5000kg/h | 450kw | 60*10*24m |
Choosing the DDarin ® Fish Feed Machine means investing in performance, reliability, and innovation—all backed by years of experience in food processing machinery. Here’s why leading pet food and snack manufacturers worldwide choose Darin:
Motors from Darin Machinery are sourced from WEG with a 3-year worldwide guarantee or Siemens.Enjoy a reliable global after-sales service system.
Electric parts are from ABB or Schneider, easy to find replacments at local market.
PLC and touch screens from Siemens, Germany, are used by Darin Machinery to ensure easier operation and reduced labor requirements.
When faults occur, Darin Machinery’s touch screens display relevant information, making it easy to diagnose and resolve issues quickly.
Darin Machinery control cabinets are equipped with 24V safe voltage, ensuring operator safety even electrical leakage occurred.
Darin Machinery includes three types of protectors over-current, over-voltage, over-heat to ensure machine and operator safety.
Servo follows the cutting size more accurately, rolling cutting can cut products with strong toughness, such as cowhide products, and the cutter does not cut the conveyor belt.
The end of the conveyor belt has a small turning radius, which makes material transportation smoother.
Its components are arranged for quick disassembly, ensuring efficient upkeep and hygienic operation.
All cover bodies, mesh belts, and parts in contact with materials at Darin Machinery are made of food-grade stainless steel 304, providing superior durability and safety.
Maximize production efficiency with the Darin® fish feed machine. Applicable for feed production in tilapia, carp, catfish, trout, and shrimp farming systems. Whether you’re upgrading a small facility or scaling industrial production, this machine ensures nutrient-retaining, water-stable pellets with minimal maintenance.
Darin Machinery provides a full-cycle, one-stop production equipment solution for all types of pet food and pet snacks, including production lines for pet dry food, pet wet food, pet semi-moist food, pet freeze-dried food, and pet raw food, as well as common pet treats production processing equipment such as pet biscuits, pet jerky, pet dental chews, pet rawhide chews, and pet training treats.
Produces low-moisture (<12%) kibble such as dog and cat food.
Produces soft pellets or treats with 15–30% moisture content.
Produces high-moisture (>50%) products, typically for canned or pouched packaging.
Specially designed for unique shapes and textures, such as dental chews or training treats.
Capacity < 500 kg/h. Suitable for small businesses, startups, or R&D purposes.
Capacity of 500–2,000 kg/h. Ideal for regional manufacturers.
Capacity > 2,000 kg/h. Designed for large-scale pet food brands and export-oriented factories.
Darin® Pet Food Extruder supports diverse applications, including dog food, cat food, fish feed, and exotic animal feed. Its advanced customization and automation ensure versatile production to meet diverse market demands. Contact us today to expand your pet food offerings!
Consult Our Experts ！Let’s work together to build your next best-seller.
Optimized for dog food formulations and kibble shapes.
Suitable for small-sized kibble and feline-specific nutritional needs.
Produces pellets or granules for various bird species.
Designed to produce floating or sinking fish feed.
Tailored for rabbits, guinea pigs, and other small mammals with high-fiber dietary requirements.
Keeping automation, quality and service in mind, always based on the diverse needs of customers, Darin will be dedicated to providing clients with satified product and full life after sales service.
Darin machines run in more than 70 countries including USA, UEA, Germany, Japan, Italy, Spain, Holland, Australia, Brazil, Mexico, Indonesia, Thailand, Canada etc.
Keeping automation, quality and service in mind, always based on the diverse needs ofcustomers, Darin will be dedicated to providing clients with satified product and full life after salesservice.
When purchasing the Fish Feed Machine, you might be interested in the following questions.
Our fish feed machine is engineered to produce various types of aquatic feed to meet different species' feeding habits and water column levels. Specifically, it can manufacture:
Description: Floats on the water surface for an extended period.
Suitable For: Surface-feeding species such as tilapia, catfish, carp, goldfish, and other ornamental fish.
Key Benefits:
Easy to monitor feeding behavior.
Reduces feed wastage.
Helps maintain water quality.
Description: Immediately sinks to the bottom after entering the water.
Suitable For: Bottom-feeding species like shrimp, crabs, eels, and some species of catfish.
Key Benefits:
Targets bottom-dwelling feeders.
Minimizes feed competition among different species.
Description: Initially stays suspended or floats briefly before gradually sinking.
Suitable For: Mid-water feeders such as trout, sea bass, largemouth bass, and snapper.
Key Benefits:
Balanced feeding option for varied feeding levels.
Reduces nutrient leaching and water contamination.
Extrusion temperature
Screw speed
Feed moisture content
Starch composition in the formula
Die configuration
Our machine allows precise control of these parameters, ensuring the production of high-quality feed tailored to your target species and growth stages.
The production capacity range of our fish feed machine depends on the model and configuration. We offer machines suitable for small-scale startups to large-scale commercial fish feed factories.
| Machine Model | Capacity (kg/h) | Application Scale |
|---|---|---|
| Small-scale line | 50–150 kg/h | Laboratory, farm trials, micro startups |
| Medium-scale line | 200–1,000 kg/h | Small to medium commercial production |
| Large-scale line | 1,000–5,000+ kg/h | Industrial-scale factories |
✅ Note: We also provide custom-designed lines with capacities up to 10,000 kg/h or more upon request.
Machine model (single-screw vs. twin-screw)
Type of feed (floating, sinking, slow-sinking)
Pellet size (0.8 mm to 12 mm or more)
Raw material formulation
Degree of automation and drying/cooling systems
Would you like us to recommend a model based on your production target, feed type, and species?
Yes — the Darin® fish feed machine is fully suitable for both freshwater and marine fish feed production.
| Fish Type | Common Species | Feed Type | Machine Compatibility |
|---|---|---|---|
| Freshwater Fish | Tilapia, Carp, Catfish, Grass Carp, Ornamental fish | Floating / Sinking / Slow-sinking | ✔ Fully Supported |
| Marine Fish | Sea Bass, Grouper, Snapper, Turbot, Yellow Croaker | High-protein sinking/slow-sinking | ✔ Fully Supported |
Advanced Extrusion Technology
Precise control of temperature, pressure, moisture, and screw speed allows the machine to produce feed tailored to the nutritional and physical requirements of both freshwater and marine species.
Flexible Formulation Handling
Compatible with high-fat and high-protein marine formulas (e.g., fishmeal, squid meal, shrimp shell powder) as well as plant-based freshwater formulas (e.g., soybean meal, corn gluten).
Customizable Pellet Size & Density
Produces pellets ranging from 0.8 mm to 12 mm or more.
Adjusts sinking behavior based on species’ feeding habits.
Corrosion-resistant Materials
Parts in contact with feed (especially oils and salts in marine formulas) are made with food-grade stainless steel, ensuring hygiene and durability.
Versatile Post-processing Systems
Integrated dryer, oil coating system, and cooling unit ensure pellet shelf-life and quality for both fresh- and salt-water use.
If you have specific marine species or production goals in mind, I can provide recommended configurations, recipes, or case studies from Darin's global clients. Would you like that?
Our fish feed machine is designed with a wide range of raw material compatibility to support diverse aquatic nutrition formulas for both freshwater and marine species.
Animal-based:
Fish meal
Shrimp/crab meal
Meat and bone meal
Poultry by-product meal
Blood meal
Plant-based:
Soybean meal
Corn gluten meal
Cottonseed meal
Peanut meal
Corn flour
Wheat flour
Rice bran
Cassava starch
Potato starch
Molasses (limited ratio for binding)
Fish oil
Soybean oil
Poultry oil
Sunflower oil
Palm oil
Premixes (A, D, E, K, B-group)
Trace minerals (Fe, Zn, Se, Mn, Cu, I, etc.)
Lecithin
Enzymes
Probiotics
Amino acids (e.g., lysine, methionine)
Antioxidants and preservatives
Squid liver powder
Fish hydrolysate
Yeast extract
Attractants for marine species
Particle size: Most materials must be pre-ground to 60–100 mesh for optimal extrusion.
Moisture content: Typically 12%–15% at feeding stage.
Fat inclusion: High-oil content (>8–10%) should be added post-extrusion via oil spraying system for stability.
Pre-grinding systems available (hammer mill, pulverizer)
Mixers and dosing systems to ensure consistent formula blending
Vacuum coating/oil sprayers for uniform fat and palatant distribution
Would you like a recommended raw material formulation based on a specific fish species or growth stage?
Absolutely — the Darin® fish feed machine is fully customizable to accommodate specific feed formulas, nutritional profiles, and pellet sizes, ensuring optimal performance for various species and production goals.
Darin’s extruder allows precise control over key variables, enabling it to process:
High-protein marine formulas (e.g., with high fishmeal or shrimp meal content)
Plant-based vegetarian formulas for herbivorous freshwater fish
Functional diets (e.g., medicated, probiotic, or slow-release feeds)
| Parameter | Adjustability |
|---|---|
| Screw configuration | Single- or twin-screw setups, customizable pitch and length |
| Barrel temperature | Multi-zone control for starch gelatinization and protein denaturation |
| Moisture level | Tuned for expansion or density control |
| Fat/oil inclusion | Pre- or post-extrusion addition via coating systems |
| Retention time | Adjustable via screw speed and barrel design |
Darin machines can produce pellets in a wide range of diameters and lengths:
| Pellet Diameter | Typical Use |
|---|---|
| 0.8–2 mm | Larval and juvenile fish |
| 2–4 mm | Grow-out stage of tilapia, carp, catfish |
| 5–8 mm | Adult fish and marine species |
| 9–12 mm+ | Special feeds or large carnivorous species |
Length Control: Adjustable via cutting blades and die shape.
Sinking behavior: Controlled by formula and extrusion conditions (floating / slow-sinking / sinking).
Variable frequency drives (VFD) for screw and cutter speed
Custom die molds for pellet shape/size
Multi-layer dryers and oil coating units
Pre-conditioning systems for higher productivity or delicate formulas
Whether you need floating pellets for tilapia, high-fat sinking feed for marine species, or micro pellets for hatcheries, Darin can tailor the machine to your exact feed specifications.
Would you like us to prepare a technical proposal based on your species, feed type, and production capacity?
Yes — our Darin® fish feed machines are manufactured in full compliance with major international quality and safety standards to ensure global market acceptance and regulatory confidence.
| Certification | Scope & Significance |
|---|---|
| CE (Conformité Européenne) | Confirms compliance with EU safety, health, and environmental protection standards. Required for exporting to Europe. |
| ISO 9001:2015 | Quality management system certification. Ensures consistent manufacturing, traceability, and product reliability. |
| ISO 22000 / HACCP (upon request) | Food safety management system applicable to feed production, especially for aquaculture feed facilities. |
| FDA Compliance (for contact surfaces) | Stainless steel parts in contact with feed ingredients can meet FDA-grade food contact safety standards. |
| SGS / BV / TUV Third-party Inspection | Available upon buyer’s request for verification of machine quality, specifications, and certifications. |
CE Certificate of Conformity
ISO 9001 Quality Management Certificate
Declaration of Materials Safety (for contact components)
Operation & Maintenance Manual
Electrical Schematic & P&ID Diagram
Installation Checklist & Acceptance Report Template
If you're exporting to a region with specific regulatory needs (e.g., EU, Middle East, North America), we can pre-configure the machine to meet local standards — including voltage, frequency, language of labels, and documentation.
Would you like to see sample certificates or a compliance pack template for your region?
The Darin® fish feed machine is available in multiple automation levels to suit different production scales, budgets, and operational preferences:
| Automation Level | Description | Typical Users |
|---|---|---|
| Manual (Entry-level) | Basic operation with manual feeding, parameter adjustments, and packaging. Requires higher operator involvement. | Small farms, R&D, startup trials |
| Semi-Automatic (Standard) | Automated extrusion and cutting; manual batching, feeding, and packaging. Basic control panel with adjustable settings. | Small to mid-sized manufacturers |
| Fully Automatic (Advanced) | Integrated PLC+HMI control system, auto batching, feeding, extrusion, drying, oil coating, cooling, and packaging. | Commercial and industrial feed factories |
PLC+Touchscreen Control (HMI)
Real-time parameter monitoring and recipe management
Auto Dosing & Mixing System
Precise weighing of multiple raw materials
Auto Extrusion & Pellet Cutting
Screw speed, barrel temp, and cutter speed automatically adjusted
Auto Drying & Oil Coating Unit
Multi-layer belt dryer and vacuum oil sprayer for uniform coating
Auto Cooling & Sieving
Ensures final pellet stability and dust removal
Optional: Packaging Line Integration
Automatic weighing, bagging, sealing, and labeling
Recipe memory and one-touch startup
Remote monitoring & diagnostics
Energy consumption tracking
Alarm system for fault detection
We recommend the semi-automatic system for mid-size operations (200–1,000 kg/h) and fully automatic lines for 1,000 kg/h and above.
Would you like a side-by-side comparison of the semi-automatic vs. fully automatic setups with estimated costs and operator requirements?
Yes — the Darin® fish feed machine can be seamlessly integrated into a complete fish feed production line, tailored to your capacity, automation level, and feed type requirements.
Storage Silos / Bins
Automatic Dosing System
Vertical or Ribbon Mixer
Bucket Elevator / Screw Conveyor
Hammer Mill / Pulverizer
Reduces particle size for optimal extrusion
Equipped with cyclone and dust collection systems
Darin® Fish Feed Extruder
Floating / sinking / slow-sinking pellets
Twin-screw or single-screw models available
PLC+HMI control for recipe adjustment
Integrated variable-speed cutter to control pellet length
Multi-layer Belt Dryer
Adjusts temperature and drying time
Ensures moisture < 12% for shelf stability
Vacuum or Rotary Oil Coater
Applies oil, flavor enhancers, vitamins post-extrusion
Enhances palatability and nutrition
Counterflow Cooler
Reduces pellet temperature to ambient
Prevents moisture condensation in storage
Rotary Screener
Removes fines and broken pellets for uniformity
Semi-auto or fully automatic packing
Weighing, bagging, sealing, labeling
All sections can be centrally controlled via PLC system
Modular design supports flexible layout & future upgrades
Available in batch or continuous operation modes
Would you like a layout diagram or flowchart of the complete fish feed production line tailored to a specific capacity (e.g. 1 ton/hour)? I can also help estimate floor space, power requirements, and staffing.
The energy consumption and power requirements of the Darin® fish feed machine depend on the model, capacity, and level of automation. Below is a general guideline based on standard configurations:
| Production Capacity | Main Extruder Power | Total Line Power (incl. mixer, dryer, etc.) | Voltage / Frequency |
|---|---|---|---|
| 50–150 kg/h (small) | 15–22 kW | 45–60 kW | 380V, 50/60Hz, 3-phase |
| 200–500 kg/h (medium) | 30–55 kW | 80–120 kW | Customizable |
| 1,000–2,000 kg/h (large) | 75–132 kW | 180–300+ kW | Customizable |
| 3,000 kg/h and above | ≥160 kW | ≥400 kW | Customizable |
💡 We can adapt to different national standards, including 220V/440V, 50Hz/60Hz, single or three-phase.
Screw and motor efficiency: Twin-screw extruders may use more power but offer higher output and flexibility.
Moisture content: Lower moisture formulas require more energy to extrude and dry.
Pellet type and density: Floating feed requires more expansion → slightly higher energy usage.
Drying method: Multi-layer belt dryers account for a major portion of total energy use.
Oil coating system: Vacuum systems require additional motorized components.
Variable Frequency Drives (VFD) for screw and cutter motors
Thermal insulation on barrel and dryer zones
Efficient gear reducers to reduce idle power loss
Optional heat recovery systems for drying air
Would you like a detailed energy cost estimation per ton of feed produced, based on your local electricity rate and target output?
The lead time for manufacturing and delivering the Darin® fish feed machine depends on the model, production line complexity, and customization level. Below is a general guideline:
| Machine Type | Lead Time (Production Only) | Total Delivery Time (Including Shipping) |
|---|---|---|
| Single fish feed extruder (stock model) | 15–20 working days | 30–45 days (by sea, depending on destination) |
| Standard semi-auto production line | 25–30 working days | 40–60 days total |
| Fully automatic large-capacity line | 35–45 working days | 55–70 days total |
| Customized turnkey projects | 45–60+ working days | 60–90+ days total |
Sea freight: Most economical for international buyers; transit times vary by destination.
Air freight: Available for small machines or urgent orders (higher cost).
Rail (e.g. to Europe): Optional for certain countries; balanced time and cost.
Order Confirmation & Down Payment → Starts production
Design & Customization Finalization (if applicable)
Assembly & Testing → Includes FAT (Factory Acceptance Test) with video or customer presence
Packaging & Shipment Preparation
Shipping & Documentation → Bill of Lading, Packing List, Commercial Invoice, CE/ISO Certificates, Manuals, etc.
To optimize lead time, we recommend:
Early confirmation of machine configuration
Clear power and voltage requirements
Advance notice if third-party inspection (e.g., SGS/BV) is needed
Would you like us to estimate a timeline based on your target delivery date and country?
The standard configuration of the Darin® fish feed machine includes all essential components required for extrusion-based fish feed production. It is designed for immediate operation upon installation, with modular upgrades available.
| Component | Description |
|---|---|
| Main Extruder | Twin-screw or single-screw extruder (based on model) with stainless steel barrel and alloy steel screws for durability and food safety. |
| Screw Shaft & Segmented Screws | Interchangeable screw elements for customized extrusion performance and easy maintenance. |
| Barrel with Heating Zones | Electrically controlled temperature zones for precise cooking and expansion control. |
| Control Cabinet | Pre-installed PLC + HMI touchscreen panel with user-friendly interface, motor controls, and safety interlocks. |
| Cutting System | Variable-speed rotary cutter at the die face; blade speed adjustable to control pellet length. |
| Standard Molds (Dies) | Set of interchangeable dies for various pellet sizes (commonly includes 1.5 mm, 2.5 mm, 4 mm, 6 mm). Custom molds can be ordered. |
| Feeding System | Horizontal or vertical screw feeder, motor-driven, for continuous feeding of mixed raw materials. |
| Lubrication System | Central or manual lubrication points for bearings and gearbox. |
| Base Frame & Covers | Heavy-duty carbon steel or stainless-steel base with protective covers and anti-vibration mounts. |
| Tool Kit | Basic maintenance tools and spare parts for initial operation. |
| Operation & Maintenance Manual | Includes technical drawings, wiring diagrams, user instructions, troubleshooting guide. |
| Electrical Components | High-quality brands such as Siemens, Schneider, or Delta (model dependent). |
| Cooling Fan / Exhaust | Installed near the control cabinet or barrel area to manage internal heat. |
Pre-conditioner (for higher-capacity or marine feed lines)
Vacuum oil spraying system
Multi-layer dryer
Cooling and screening units
Packaging machine
Remote monitoring module
Would you like a photo or technical layout of the standard extruder configuration? I can also help compare two models side-by-side based on your capacity needs.
Yes — to build a complete and efficient fish feed production system, Darin® offers a wide range of optional accessories that can be integrated with the fish feed extruder. These modular components enhance production capacity, feed quality, automation level, and post-processing.
| Accessory | Function | Availability |
|---|---|---|
| 1. Pre-conditioner | Pre-cooks and hydrates raw material before extrusion, improves pellet quality | ✔ Recommended for high-protein/marine feed |
| 2. Multi-layer Belt Dryer | Reduces moisture content to below 12% for stable storage; temperature adjustable | ✔ Essential for commercial production |
| 3. Cooling Machine (Counterflow Cooler) | Cools hot pellets post-drying to ambient temperature to prevent condensation | ✔ Highly recommended |
| 4. Vacuum Oil Coating Machine | Sprays oil, palatants, or vitamins evenly onto pellet surface after drying | ✔ Essential for high-fat or marine diets |
| 5. Rotary Screener / Sifter | Removes broken pellets and fines, improves product uniformity | ✔ Improves quality control |
| 6. Air Conveyor or Bucket Elevator | Transports feed between sections automatically (e.g., extruder → dryer) | ✔ Supports continuous line operation |
| 7. Storage Bins / Silos | Temporary holding before packaging, helps buffer process sections | ✔ Optional |
| 8. Automatic Packaging Machine | Weighing, filling, sealing, and labeling of finished pellets into bags | ✔ Available in semi-auto or fully automatic |
| 9. Dust Collector System | Captures dust from grinding/mixing processes to maintain clean environment | ✔ Optional |
| 10. Metal Detector | Ensures feed safety by detecting metal contaminants before packaging | ✔ Optional for export-grade production |
All accessories are modular and can be configured according to layout and capacity.
Electrical control can be centralized via PLC + HMI for full automation.
Optional components comply with CE/ISO/FDA upon request.
Would you like a tailored line layout with specific accessories based on your target capacity (e.g., 1,000 kg/h) and fish species? I can provide a full process flow and footprint recommendation.
Please Contact for the Details.
Yes — Darin® Machinery warmly welcomes all clients for factory visits and offers live demonstrations of the fish feed machine, both in-person and virtually.
We are pleased to host you at our manufacturing facility in Jinan, Shandong, China, where you can:
Inspect our fish feed extruders and production lines in operation
Review build quality, materials, and configuration details
Discuss customization needs with our technical team
Observe packaging, control systems, and post-processing equipment
Review warehouse, spare parts inventory, and assembly zones
➡️ Advance booking is required so we can prepare demo materials and staff support.
If you are unable to travel, we offer professional remote demonstrations via Zoom, WhatsApp, or Teams, including:
Real-time walk-through of the workshop
Full machine operation demonstration (start-up, feeding, extrusion, cutting)
Detailed Q&A with our engineers
Close-up views of control panel, screw/barrel, molds, final pellets
Live testing with your requested feed formula (optional)
Video recording of demonstration (for later review or team sharing)
Sample pellets can be shipped to you after testing
Multilingual support available (English, Spanish, Russian, etc.)
Would you prefer to schedule a virtual demo, or would you like an invitation letter for your visa and travel arrangements? We can coordinate a tailored visit plan based on your species, feed type, and machine model of interest.
Yes — installation and commissioning services are available with the purchase of the Darin® fish feed machine, and they can be included as part of the official sales agreement depending on your needs and budget.
| Service Type | Included by Default | Optional Add-on |
|---|---|---|
| Remote installation support (video/online) | ✅ Yes | — |
| On-site installation by Darin engineers | — | ✔ Yes (quoted separately) |
| Commissioning & trial run | ✅ Yes (remote or on-site) | ✔ On-site optional |
| Operator training (remote) | ✅ Yes | — |
| Operator training (on-site) | — | ✔ Available if requested |
Supervision of machine installation and layout alignment
Electrical and mechanical setup check
Commissioning and test production with your raw materials
Tuning of pellet size, density, and moisture
Troubleshooting and adjustments
Operator training: control panel use, maintenance, cleaning procedures
Acceptance report with performance verification
⚠️ On-site service fees typically include daily rate for engineers, travel expenses (flights, visas, hotel, meals), and local transportation.
Step-by-step installation guides with wiring diagrams
Video tutorials for mechanical and electrical setup
Real-time video support via WhatsApp/WeChat/Zoom during installation
PDF manuals and startup checklists
Technical hotline and email support
Would you prefer a quotation that includes on-site installation and training services? If so, please share your installation location and desired commissioning date so we can calculate the full package.
Darin® provides comprehensive training for operating the fish feed machine, ensuring your team can run the system safely, efficiently, and independently — whether through remote guidance or on-site support.
| Training Method | Availability | Details |
|---|---|---|
| Remote Training (Standard) | ✅ Included with every purchase | Via video call, user manuals, video tutorials |
| On-Site Training (Optional) | ✔ Available upon request | Delivered by Darin engineers during installation |
| Live Demonstration (Optional) | ✔ During factory visit or remote demo | Hands-on training at Darin factory or via Zoom/WhatsApp |
Equipment layout and assembly
Electrical wiring and water/air connections
Control panel introduction and safety precautions
Raw material feeding and mixing
PLC or HMI interface walkthrough
Recipe input, temperature control, screw speed adjustment
Pellet size/density control (cutting system + die changes)
Daily, weekly, and monthly maintenance schedules
Lubrication points and parts replacement guide
How to disassemble and clean screws, barrel, and cutter
Trouble signs and early warning indicators
Common faults (e.g., motor overload, pellet inconsistencies)
How to handle alarms and system errors
Preventive measures for downtime reduction
Operator’s Manual (PDF + printed)
Electrical wiring diagram & flowchart
Video tutorials (machine start-up, shutdown, cleaning)
Spare parts usage and maintenance guide
Online Q&A follow-up after training
Would you like a sample of the training manual or tutorial videos for your internal review? We can also provide a tailored training outline based on your staff’s technical background.
The dimensions and shipping weight of the Darin® fish feed machine vary depending on the model, capacity, and whether you're purchasing the extruder alone or the full production line.
Below is a general reference for the main extruder unit only:
| Model Capacity | Extruder Dimensions (L×W×H) | Approx. Shipping Weight |
|---|---|---|
| 50–150 kg/h (small) | 2.2 × 1.0 × 1.5 m | 800–1,000 kg |
| 200–500 kg/h (medium) | 3.0 × 1.2 × 2.0 m | 1,200–2,000 kg |
| 1,000–2,000 kg/h (large) | 4.5 × 1.5 × 2.2 m | 2,500–4,000 kg |
| 3,000 kg/h and above | 5.5 × 2.0 × 2.5 m+ | 5,000–8,000 kg+ |
⚠️ These figures apply to the extruder only. If purchasing a full production line (dryer, mixer, cooler, etc.), total shipping volume and weight can reach 2–4× higher.
Machines are packed in strong plywood cases or steel-framed containers
Export-standard packaging suitable for sea, rail, or air freight
Shipping method depends on destination and urgency
If you're purchasing a complete line, we’ll provide a detailed packing list with:
Equipment name/model
Crate dimensions (L×W×H)
Net/gross weight
Total volume (CBM)
Container type recommendation (20GP / 40GP / 40HQ)
Would you like us to calculate total packing dimensions and container loading plan based on a specific capacity (e.g. 1 ton/hour full line)?
The Darin® fish feed machine is protected using export-standard packaging to ensure safe, damage-free delivery under various shipping conditions (sea, rail, or air freight). We strictly follow international logistics safety guidelines.
| Packaging Element | Details |
|---|---|
| 1. Protective Wrapping | All machine surfaces are wrapped in plastic film or anti-corrosion stretch wrap to prevent moisture, dust, and rust during transit. |
| 2. Shockproof Padding | Key components (e.g., control cabinet, motor, cutter) are cushioned with foam or anti-vibration material to minimize impact during loading/unloading. |
| 3. Fumigated Wooden Case | Machines are packed in strong, export-grade plywood crates or wooden boxes, heat-treated and certified for international shipping. |
| 4. Steel Frame (for large units) | Heavier or oversized units may be mounted on welded steel frames for added support and forklift handling. |
| 5. Waterproof Marking Labels | Crates are labeled with handling instructions, equipment names, gross/net weights, and fragile/up arrows for customs and port handlers. |
Desiccant bags inside crates to prevent humidity damage
Vacuum-sealed packaging for long sea voyages or tropical regions
Shock indicators and tilt sensors for sensitive electronics or PLC systems
Crate barcoding & itemized packing list for easy customs clearance
Packed according to space optimization in 20GP, 40GP, or 40HQ containers
Machines are secured with steel wires and wood blocking to prevent movement during sea transport
Would you like photos or a sample packing list from a recent shipment (e.g. 1-ton/hour fish feed line) to share with your logistics team or freight forwarder?
The Darin® fish feed machine comes with a standard warranty period of 12 months from the date of arrival at the buyer’s site (or 14 months from shipment date, whichever comes first), covering core components and manufacturing quality.
| Component | Warranty Coverage |
|---|---|
| Main motor and gearbox | ✔ Covered for mechanical failure not caused by misuse |
| Screw & barrel | ✔ Covered for material or manufacturing defects (normal wear excluded) |
| PLC & electrical components | ✔ Covered for functional defects or faulty installation |
| Control panel (HMI) | ✔ Touchscreen and internal wiring covered under normal use |
| Bearings, couplings, belts | ✔ Defects in material or workmanship covered |
| Cutting knife system | ✔ Structural or mechanical defects covered |
| Sensors & temperature controllers | ✔ Functional failure covered under normal use |
| Mixer, dryer, cooler (if included) | ✔ All major drive motors and control systems covered |
Wear-and-tear parts (e.g., cutter blades, bushings, seals, O-rings)
Damage due to improper operation, voltage mismatch, overloading, or poor maintenance
Corrosion or damage caused by uncleaned high-protein/oily materials
Unauthorized disassembly or third-party modification
Shipping-related physical damage (can be covered by shipping insurance)
Free spare parts kit included with the machine (e.g., gaskets, wrenches, belts, blades)
Fast-shipping parts service: Most components are in stock and can ship within 24–72 hours
Remote diagnosis & troubleshooting via video or online support included for life
Extended warranty plans available (18–24 months) — quoted separately
Would you like a full warranty certificate sample or a recommended spare parts list for your selected model?
Darin® provides comprehensive spare parts support and maintenance service for all fish feed machines to ensure your production runs smoothly, efficiently, and with minimal downtime.
Each machine comes with a starter set of wear-and-tear parts, which typically includes:
Cutter blades
Heating elements
Seals and gaskets
Belts and bushings
Wrenches and basic tools
You will receive a spare parts manual with part codes, names, and diagrams — making future ordering easy and accurate.
Common spare parts are kept in stock at our warehouse and available for immediate dispatch (within 24–72 hours)
Parts are guaranteed to be available for at least 10 years after purchase
Non-standard or high-wear parts (e.g., custom molds, special screws) can be fabricated on-demand with short lead times
Comprehensive daily / weekly / monthly maintenance schedules
Guides on cleaning, lubrication, screw removal, barrel cleaning, and fault diagnosis
Lifetime online support via video call, email, WhatsApp, or WeChat
Troubleshooting assistance, software updates, parameter tuning, and operator refresher guidance
Available for major repairs, rebuilds, or training refresh
Billed by service day + travel expenses
Provide part code or description (photos accepted)
Darin team confirms compatibility and price
Parts shipped via express courier (DHL, FedEx, etc.) or air/sea freight
Would you like a recommended spare parts stock list for 1–2 years of operation or a spare parts quotation for your specific model and expected production hours?
The average service life of the core components of the Darin® fish feed machine depends on usage intensity, raw material type, maintenance frequency, and operational settings. That said, our machines are built with durable industrial-grade components and designed for long-term operation.
| Component | Estimated Service Life | Remarks |
|---|---|---|
| Main motor | 8–10 years (or more) | From top brands like Siemens or equivalent; life extended with proper voltage and load |
| Gearbox / Reducer | 6–10 years | Heavy-duty build; periodic lubrication required |
| Screw elements | 1,500–3,000 operating hours (normal wear) | Depends on formulation abrasiveness and cleaning frequency |
| Barrel segments | 3–5 years | Wear-resistant alloy lining; longer life with high-quality materials |
| Cutting blades | 300–800 hours (replaceable) | Sharpening or replacement required depending on feed hardness |
| Bearings & seals | 1–3 years | Regularly greased and replaced as part of preventive maintenance |
| Heating elements | 2–4 years | Depends on stability of power supply and operating temperature |
| PLC & electrical parts | 5–10 years | Industrial-grade, typically maintenance-free under proper conditions |
Use properly pre-ground and mixed feedstock
Regular cleaning and lubrication (follow our O&M manual)
Avoid running machine under overload or voltage fluctuations
Install inline magnetic separators to reduce metal wear
Keep extruder within designed moisture and fat input ranges
For normal commercial use (8–10 hours/day), we recommend stocking:
Screw elements: 1 full set every 12–18 months
Cutting knives and bushings: Monthly or quarterly
Bearings/seals: 1–2 sets per year
Would you like a detailed spare parts usage forecast or annual maintenance schedule based on your target production hours?
Yes — Darin® provides both remote technical support and optional on-site maintenance services for our fish feed machines to ensure continuous, reliable operation for your facility.
Included free of charge for all customers:
| Service Type | Details |
|---|---|
| Live Video Support | Real-time troubleshooting via Zoom, WhatsApp, WeChat, or Teams |
| Step-by-Step Guides | PDF manuals, wiring diagrams, parameter setting sheets |
| Training Videos | Operation, cleaning, lubrication, die change, and fault handling |
| Software Updates | PLC/HMI firmware updates and troubleshooting via USB or online upload |
| Response Time | Within 24 hours on business days; emergency support available |
✅ This support continues for the lifetime of the machine.
Available globally upon request (subject to quotation):
| Service | Availability |
|---|---|
| Installation & Commissioning | ✔ Yes |
| Routine Maintenance Visit | ✔ Yes (annual contracts available) |
| Emergency Breakdown Repair | ✔ Yes (subject to visa/travel availability) |
| Operator Re-training | ✔ Yes (onsite or remote) |
System diagnostics & fault resolution
Replacement of worn components
Recalibration of control system
Performance tuning & recipe optimization
Operator skill refresh
💡 Travel costs (flights, hotel, local transport) and daily service rate apply.
Spare parts fast dispatch (24–72 hrs)
Online knowledge base with fault codes and solutions
Optional remote monitoring module (for real-time telemetry & alerts)
Would you like a technical service contract proposal or a list of recommended spare parts and tools to keep on-site for faster self-repair?
Yes — the software and firmware of the Darin® fish feed machine can be upgraded remotely under supported configurations, especially for models equipped with PLC + HMI control systems (e.g., Siemens, Delta, or similar industrial-grade platforms).
| Component | Upgradable | Method |
|---|---|---|
| PLC (Programmable Logic Controller) | ✔ Yes | Firmware/logic program updates via USB or remote connection |
| HMI (Touchscreen Interface) | ✔ Yes | Interface optimization, language updates, recipe presets |
| Parameter Settings / Recipes | ✔ Yes | Downloadable or remotely uploaded via USB or SD card |
| Control Logic Optimization | ✔ Yes | Darin engineers can guide or send files for upload |
| Remote Troubleshooting Add-on | ✔ Optional | Ethernet-enabled PLC can support remote login for updates |
USB or SD Card Upload
We send update package (.PLC / .HMI files) with step-by-step instructions
Can be done by your operator in minutes
Remote Access (If Supported)
For machines with Ethernet-enabled PLCs, Darin can securely connect (via TeamViewer, VNC, or VPN)
Direct update and diagnostics by our technicians
Factory Preloaded Updates
For older machines, firmware can be upgraded during scheduled maintenance or by sending the control unit to our factory (if needed)
All firmware/software packages are signed and verified
Backup of current settings is created before any update
Darin provides post-update testing support to ensure system performance
Would you like to know if your specific model supports remote firmware updates, or are you interested in adding a remote access module for long-term support convenience?
Yes — Darin® provides a complete set of production troubleshooting guides and video tutorials to ensure your team can operate and maintain the fish feed machine with confidence and minimal downtime.
The printed and digital guide includes:
| Section | Contents |
|---|---|
| Startup & Shutdown Checklist | Step-by-step procedures to ensure safe operation |
| Common Fault Codes & Solutions | For PLC/HMI systems — alarms, sensor errors, temperature issues |
| Pellet Quality Issues | How to fix under-expansion, breakage, inconsistent size, sinking/floating problems |
| Extruder Problems | Screw jamming, barrel overheat, back pressure issues, material buildup |
| Feeding & Mixing Errors | Blockages, uneven feeding, moisture variation handling |
| Drying & Coating Faults | Uneven drying, oil coating issues, pellet discoloration |
| Electrical/Mechanical Failures | Fuse trips, motor faults, drive overloads, belt slippage |
🔧 Each issue is paired with probable causes and recommended corrective actions.
Accessed via USB, cloud folder, or QR code in the manual:
| Tutorial Topic | Description |
|---|---|
| Machine installation & wiring | Full step-by-step walkthrough |
| Control panel (PLC/HMI) operation | Set recipes, monitor parameters, adjust pellet size |
| Feeding and extrusion startup | How to load and extrude different feed types |
| Die change and cutter adjustment | Change pellet size, tune blade speed |
| Cleaning and daily maintenance | How to safely disassemble, clean, and reassemble |
| Screw/barrel maintenance | How to inspect, clean, and replace worn parts |
| Troubleshooting scenarios | Real cases with solutions shown on camera |
Remote one-on-one video assistance available anytime
Live training sessions via Zoom/Teams for new operators
Refresher videos available upon firmware or recipe updates
Would you like a sample troubleshooting page or preview links to the tutorial videos? I can also suggest a recommended training schedule for your operating team.
Great question. Below is a structured summary of the most common failures that may occur with a fish feed machine (extruder-based), along with causes and practical solutions, based on Darin®’s experience with global installations:
| Issue | Possible Cause | Solution |
|---|---|---|
| 1. No material discharge / blocked extrusion | - Screw jamming |
Raw material moisture too low
Foreign object inside barrel | - Check and clean screw/barrel
Adjust feed moisture (12–15%)
Inspect and remove any blockage |
| 2. Unstable pellet shape or size | - Worn or misaligned die
Inconsistent raw material mixing
Cutter speed mismatch | - Replace or clean die
Ensure consistent mixing in pre-processing
Adjust cutter motor speed |
| 3. Pellet not floating / too dense | - Low starch content
Insufficient barrel temperature
Incorrect screw configuration | - Add more starch (10–15%)
Increase preconditioning or barrel temp
Optimize screw layout |
| 4. Pellet breakage / powdering | - Overdrying
Die too small or worn
Low binder or fat in formula | - Reduce dryer temperature or time
Replace die
Adjust formulation (add binder/fat) |
| 5. Motor overload or sudden stop | - Material buildup or blockage
Overfeeding
Bearing or gearbox issues | - Stop machine and clean barrel
Adjust feed rate
Inspect motor/bearing temperature and lubricate |
| 6. Abnormal noise / vibration | - Loose bolts or couplings
Worn bearings or misaligned shafts
Screw damage | - Tighten mechanical parts
Replace bearings
Inspect and replace screw if needed |
| 7. Control panel (HMI/PLC) not responding | - Power fluctuation
Faulty wiring or screen
Software crash | - Check power supply and wiring
Reboot system
Contact Darin for firmware reload |
| 8. Oil coating not uniform | - Clogged nozzles
Low oil temperature or poor atomization
Uneven feed flow | - Clean sprayer
Warm oil to improve flow
Adjust flow rate or use vacuum coater |
| 9. Dryer not working properly | - Fan motor failure
Belt misalignment
Temperature sensor fault | - Inspect fan and motor
Adjust belt tension
Calibrate or replace temperature sensor |
| 10. Output below rated capacity | - Screw wear
Raw material variation
Moisture or feed rate too low | - Replace worn screw elements
Adjust formulation
Recalculate feed input rate |
Conduct daily cleaning of screws and feeding zones
Follow the lubrication schedule for motors and bearings
Keep a spare parts stock of high-wear items (cutters, seals, heating elements)
Regularly calibrate sensors and check HMI logs
Maintain proper voltage and grounding to protect the control system
Would you like a printable version of this failure chart or integrate it into your training manual or operator SOPs? I can also provide a customized preventive maintenance checklist based on your production hours.
Explore trends, tips, and innovations in Pet Food Extruder. Enhance efficiency and quality with expert insights.
Making homemade dry dog food is a rewarding way to ensure your pet receives balanced nutrition
Making homemade dry dog food is a rewarding way to ensure your pet receives balanced nutrition
Making homemade dry dog food is a rewarding way to ensure your pet receives balanced nutrition
Making homemade dry dog food is a rewarding way to ensure your pet receives balanced nutrition
Making homemade dry dog food is a rewarding way to ensure your pet receives balanced nutrition
Making homemade dry dog food is a rewarding way to ensure your pet receives balanced nutrition
let’s talk about how we can help you achieve your goals and take your business to increase !
Tell us as specific as possible of your needs.
We will work on the best solution & quote according to your requirements.
We will start production after getting your approval and deposit, and we will handle the shipment.
· Don’t worry, we hate spam too !
· Call only when multiple emails unanswered !
English
Français
Español
Português
Italiano
العربية
Русский
